PDF GUIDE
THE COMPLETE GUIDE
HorizonLite installation
The main reference for preparation, fitting and finishing your rooflight.
Open the PDF guideCAMBRIDGE HORIZONLITE
A clear guide.
A confident fit.
The installation information for our fixed frameless HorizonLite range, all in one place. Share it with your installer before work begins.
START WITH THE RIGHT INFORMATION
One range. Three useful guides.
Read the complete PDF guide, then use the video for your roof type alongside it.
WATCH THE PROCESS
On a flat roof
See the HorizonLite installation video for a flat roof project.
Open on YouTubeWATCH THE PROCESS
On a pitched roof
See the HorizonLite installation video for a pitched roof project.
Open on YouTubeTHE SIZE THAT MATTERS
Internal size.
Roof opening.
The same measurement.
Choose the pair of dimensions that matches your roof opening. Every HorizonLite fits in portrait or landscape.
- Internal size / roof opening
- 800 × 2000 mm
- Overall rooflight
- 1000 × 2200 mm
- Net weight
- 91 kg
The overall rooflight is 100 mm larger on each side. Follow the PDF guide for the upstand and fitting details.
EITHER WAY ROUND
Portrait or landscape. The same rooflight, with the same roof opening.
The diagram shows the internal opening dimensions.BEFORE WORK BEGINS
A little preparation.
A smoother installation.
Arrange installation with your own professional installer. We supply the HorizonLite rooflight and the information to help them prepare.
Share the guide
Give your installer the PDF and relevant video before the opening is prepared. Use the guide for the roof, upstand and fitting requirements.
Match the opening
Your selected internal size is the roof opening size. Check both dimensions, the overall rooflight size and your chosen orientation.
Plan the handling
Check the net weight for your size and arrange suitable handling and lifting with your installer.
Is the internal size the same as the roof opening?
Yes. The internal size shown for every HorizonLite is the size of the roof opening. An 800 × 2000 mm rooflight fits an opening of 800 × 2000 mm, or 2000 × 800 mm if rotated.
Can I fit it in portrait or landscape?
Yes. The two dimensions can run either way round. There is no fixed width or length, so reversing the dimensions does not change the rooflight you order.
Which guide should my installer use?
Start with the complete HorizonLite PDF guide. Use the flat roof or pitched roof video alongside it, depending on your project.
Do Cambridge Skylights provide installation?
We supply HorizonLite rooflights. You arrange installation with your own professional installer, using our guide and videos to help them prepare.
Can you send me a copy of the guide?
Yes. Contact our team with your HorizonLite size or order number and we can help you find the relevant installation information.
HORIZONLITE HELP
A question before you fit?
Talk to us about your selected size or installation information.
